Blow Molding Machine
Advantage
1. It adopts the preform non-reversing horizontal device, simple structure, convenient maintenance, and effectively reduces the replacement cost of parts. 2. The heating pitch between the preforms is small, the heating space of the lamp tube is effectively used, and the heating efficiency and energy saving effect of the preforms are improved. 3. The clamping machine adopts cam linkage, no chain plate pin shaft, small size and long service life. 4. Using hard claws to take the blanks and take the bottles is more stable, not easy to wear, and has a long service life 5. The stretching and blowing station is driven by a servo motor, and the bottom mold is linked with a structure. Equipped with high-speed and precise air blowing valve group to meet the requirements of high productivity. 6. The air inlet, pre-blowing, and blowing pipes use hard pipes, and the air source is cleaner and pollution-free. 7. The blowing mold is equipped with slideways, which makes it easy to change the mold. 8. The man-machine interface control system uses a 9-inch screen to complete one screen, and the operation is simple.
Scope Of Application
Parameter


Item


Unit
AL-2
AL-2S
AL-3
AL-3S

Theoretical output

Pcs/h
2500
3000
3500
4000
Product
Max. Volume
L
2.0
2.0
2.0
2.0
Max. Height
mm
320
320
320
320
Max. Diameter
mm
105
105
105
105
Mold
Number Of Cavities
/
2
2
3
3

Electrical

Power

220-380V
50-60Hz
220-380V
50-60Hz
220-380V
50-60Hz
220-380V
50-60Hz

Total Power

KW
22
22
30
30
Heating Power
KW
20
20
25
25
Air System
Operation Pressure
Mpa
0.8-1.0
0.8-1.0
0.8-1.0
0.8-1.0

Action Air Consuming

M3/min
1.0
1.0
1.6
1.6

Blowing Pressure

Mpa
3.0-4.0
3.0-4.0
3.0-4.0
3.0-4.0
Blowing Air Consuming
M3/min
2.4
2.4
2.4
3.2
Machine
Main Body Dimension(LxWxH)
M
2.66×1.60×2.3
2.66×1.60×2.3
3.3×1.85×2.3
3.3×1.85×2.3
Main Body Weight
KG
2000
2000
2500
2500
Preform Autoloader
M
2.0×1.1×2.6
2.0×1.1×2.6
2.0×1.1×2.6
2.0×1.1×2.6

Preform Automatic Weight

KG
200
200
200
200
