Cap Folding Machine
Advantage
Folding machine is developed for some special cap that with “corrugated” band. This type cap must need a folding process after molding in order to allow a proper capping. It is able to satisfy different customer with different capacity and different equipment.
Scope Of Application
Parameter


SY-200 Cap Folding Machine
Type

Capacity

(Pcs/hr)

Diameter of Cap
Height of Cap
Mold Number
Actual Power Consumption
Conveyor Belt Electric Motor Power
Voltage
Machine weight/Net weight
Dimensions/L*W*H
10T
8000-12000
22-45mm
10-25mm
10 Cavity
0.75KW
0.5KW
220v/380v
50-60hz
300kg
1900*750*1200mm
15T
15000-20000
22-45mm
10-25mm
15 Cavity
1.1KW
0.5KW
220v/380v
50-60hz
340kg
1900*750*1200mm
20T
25000-30000
22-35mm
10-25mm
20 Cavity
1.1KW
0.5KW
220v/380v
50-60hz
400kg
2000*800*1200mm
