Compression Molding Machine
Advantage
SY-30B plastic cap molding machine is the second generation bottle cap making technical innovation. The caps made from this machine are smooth and nice, without injection dot, cap dimension is stable and reliable, compare with the same power injection machine, output increase threefold. It doesn’t have the hot runner waste material, the raw material utilization rate shall reach 98%. Moreover, this machine saves the cost of labor, small floor space, save the energy.
SY-30B plastic cap molding machine (Mechanistic) has obtained national patent and “CE” certificate.
Scope Of Application
Parameter


SY-30B Compression Molding Machine
Type
Raw Materials

Capacity

(Pcs/hr)

Diameter of Cap
Height of Cap
Mold Number
Actual Power Consumption
Air compressor (provide by userself）
Voltage
Machine weight/Net weight
Dimension/L*W*H
24T(Computer Type)
PP/HDPE/
LDPE
8000-10000
(¢28)
22-32mm
10-25mm
24 Cavity
8-10kw
0.6mpa;0.8m3
220v60hz /380v50h
2800kg
2400*1300*1700mm
24T(Manual Type)
PP/HDPE/
LDPE/ABS
7000-8000
(¢28)
22-32mm
10-25mm
24 Cavity
8-10kw
0.6mpa;0.8m3
220v60hz /380v50h
2800kg
2400*1300*1700mm
Select Industry
No matter what industry you are in, we can provide the perfect solution for your bottle cap needs.
